No. | Genset | Engine | Alternator | Controller | |||||||||||
Model | Phase | Prime/standby (kW) | Prime/standby(kVA) | Voltage | Freq. (Hz) | Model | Make | Power (kW) | Speed (rpm) | Model | Make | Power (kW) | Model | Make | |
1 | ZPW20GF | 3 | 20/22 | 25/28 | 400 | 50 | WP2.3D25E200 | WEICHAI | 23 | 1500 | ZP-184B | Zontop | 22 | HGM6110 | SmartGen |
2 | ZPW25GF | 3 | 25/28 | 31/34 | 400 | 50 | WP2.3D33E200 | WEICHAI | 30 | 1500 | ZP-184C | Zontop | 25 | HGM6110 | SmartGen |
3 | ZPW30GF | 3 | 30/33 | 38/42 | 400 | 50 | WP2.3D40E200 | WEICHAI | 36 | 1500 | ZP-224A | Zontop | 30 | HGM6110 | SmartGen |
4 | ZPW40GF | 3 | 40/44 | 50/55 | 400 | 50 | WP2.3D48E200 | WEICHAI | 44 | 1500 | ZP-224C | Zontop | 40 | HGM6110 | SmartGen |
5 | ZPW50GF | 3 | 50/55 | 63/69 | 400 | 50 | WP4.1D66E200 | WEICHAI | 60 | 1500 | ZP-224D | Zontop | 50 | HGM6110 | SmartGen |
6 | ZPW60GF | 3 | 60/66 | 75/83 | 400 | 50 | WP4.1D80E200 | WEICHAI | 72 | 1500 | ZP-224E | Zontop | 60 | HGM6110 | SmartGen |
7 | ZPW75GF | 3 | 75/83 | 94/103 | 400 | 50 | WP4.1D100E200 | WEICHAI | 90 | 1500 | ZP-274A | Zontop | 80 | HGM6110 | SmartGen |
8 | ZPW80GF | 3 | 80/88 | 100/110 | 400 | 50 | WP4.1D100E200 | WEICHAI | 90 | 1500 | ZP-274A | Zontop | 80 | HGM6110 | SmartGen |
9 | ZPW100GF | 3 | 100/110 | 125/138 | 400 | 50 | WP6D132E200 | WEICHAI | 120 | 1500 | ZP-274B | Zontop | 100 | HGM6110 | SmartGen |
10 | ZPW120GF | 3 | 120/132 | 150/165 | 400 | 50 | WP6D152E200 | WEICHAI | 138 | 1500 | ZP-274C | Zontop | 120 | HGM6110 | SmartGen |
11 | ZPW150GF | 3 | 150/165 | 188/207 | 400 | 50 | WP10D200E200 | WEICHAI | 182 | 1500 | ZP-274E | Zontop | 150 | HGM6110 | SmartGen |
12 | ZPW200GF | 3 | 200/220 | 250/275 | 400 | 50 | WP10D238E200 | WEICHAI | 216 | 1500 | ZP-274H | Zontop | 200 | HGM6110 | SmartGen |
13 | ZPW250GF | 3 | 250/275 | 313/344 | 400 | 50 | WP10D320E200 | WEICHAI | 291 | 1500 | ZP-314B | Zontop | 250 | HGM6110 | SmartGen |
14 | ZPW300GF | 3 | 300/330 | 375/413 | 400 | 50 | WP13D385E200 | WEICHAI | 350 | 1500 | ZP-314D | Zontop | 300 | HGM6110 | SmartGen |
15 | ZPW350GF | 3 | 350/385 | 438/482 | 400 | 50 | WP13D440E310 | WEICHAI | 392 | 1500 | ZP-354A | Zontop | 360 | HGM6110 | SmartGen |
16 | ZPW400GF | 3 | 400/440 | 500/550 | 400 | 50 | WP13D490E310 | WEICHAI | 450 | 1500 | ZP-354B | Zontop | 400 | HGM6110 | SmartGen |
17 | ZPW450GF | 3 | 450/495 | 563/619 | 400 | 50 | 6M33D572E200 | WEICHAI | 520 | 1500 | ZP-354C | Zontop | 450 | HGM6110 | SmartGen |
18 | ZPW500GF | 3 | 500/550 | 625/688 | 400 | 50 | 6M33D633E200 | WEICHAI | 575 | 1500 | ZP-354E | Zontop | 500 | HGM6110 | SmartGen |
19 | ZPW600GF | 3 | 600/660 | 750/825 | 400 | 50 | 6M33D725E310 | WEICHAI | 675 | 1500 | ZP-404A | Zontop | 600 | HGM6110 | SmartGen |
20 | ZPW650GF | 3 | 650/715 | 813/894 | 400 | 50 | 8M33D800E200 | WEICHAI | 730 | 1500 | ZP-404C | Zontop | 728 | HGM6110 | SmartGen |
21 | ZPW700GF | 3 | 700/770 | 875/963 | 400 | 50 | 12M26D902E200 | WEICHAI | 820 | 1500 | ZP-404C | Zontop | 728 | HGM6110 | SmartGen |
22 | ZPW750GF | 3 | 750/825 | 938/1032 | 400 | 50 | 12M26D902E200 | WEICHAI | 820 | 1500 | ZP-404D | Zontop | 800 | HGM6110 | SmartGen |
23 | ZPW800GF | 3 | 800/880 | 1000/1100 | 400 | 50 | 12M26D968E200 | WEICHAI | 880 | 1500 | ZP-404D | Zontop | 800 | HGM6110 | SmartGen |
24 | ZPW900GF | 3 | 900/990 | 1125/1238 | 400 | 50 | 12M33D1108E200 | WEICHAI | 1007 | 1500 | ZP-404E | Zontop | 900 | HGM6110 | SmartGen |
25 | ZPW1000GF | 3 | 1000/1100 | 1250/1375 | 400 | 50 | 12M33D1210E200 | WEICHAI | 1100 | 1500 | ZP-404F | Zontop | 1000 | HGM6110 | SmartGen |
26 | ZPW1100GF | 3 | 1100/1210 | 1375/1513 | 400 | 50 | 12M33D1320E200 | WEICHAI | 1200 | 1500 | ZP-454A | Zontop | 1120 | HGM6110 | SmartGen |
27 | ZPW1200GF | 3 | 1200/1320 | 1500/1650 | 400 | 50 | 12M33D1500E310 | WEICHAI | 1350 | 1500 | ZP-454B | Zontop | 1240 | HGM6110 | SmartGen |
28 | ZPW1200GF | 3 | 1250/1375 | 1563/1719 | 400 | 50 | 16M33D1530E310 | WEICHAI | 1390 | 1500 | ZP-454C | Zontop | 1320 | HGM6110 | SmartGen |
29 | ZPW1400GF | 3 | 1400/1540 | 1750/1925 | 400 | 50 | 16M33D1680E310 | WEICHAI | 1530 | 1500 | ZP-454D | Zontop | 1440 | HGM6110 | SmartGen |
30 | ZPW1500GF | 3 | 1500/1650 | 1875/2063 | 400 | 50 | 16M33D1800E310 | WEICHAI | 1680 | 1500 | ZP-454E | Zontop | 1520 | HGM6110 | SmartGen |
31 | ZPW1600GF | 3 | 1600/1760 | 2000/2200 | 400 | 50 | 16M33D1980E310 | WEICHAI | 1800 | 1500 | ZP-454F | Zontop | 1640 | HGM6110 | SmartGen |
 | Unit Configuration Selection | Zontop Solutions | ||||||||||||||
| Diesel Generator Set | Motor | Generator | Controller | Size | ||||||||||||
| No. | Model | Mutually | Active/Standby Power (KW) | Main/Backup Power (KVA) | Voltage (V) | Frequency (HZ) | Model | Brand | Power (KW) | Speed (RPM) | Model | Brand | Power (KW) | Brand | Brands available include Zhongzhi, Dankong, Shenhai, and Kemai. | |
| 64 | ZPW20GF | 3 | 20/22 | 25/28 | 400 | 50 | WP2.3D25E200 | WEICHAI | 23 | 1500 | ZP184B | Zontop | 22 | HGM6110 | SmartGen | 2200*900*1300 |
| 65 | ZPW25GF | 3 | 25/28 | 31/34 | 400 | 50 | WP2.3D33E200 | WEICHAI | 30 | 1500 | ZP184C | Zontop | 25 | HGM6110 | SmartGen | 2200*900*1300 |
| 66 | ZPW30GF | 3 | 30/33 | 38/42 | 400 | 50 | WP2.3D40E200 | WEICHAI | 36 | 1500 | ZP224A | Zontop | 30 | HGM6110 | SmartGen | 2200*900*1300 |
| 67 | ZPW40GF | 3 | 40/44 | 50/55 | 400 | 50 | WP2.3D48E200 | WEICHAI | 44 | 1500 | ZP224C | Zontop | 40 | HGM6110 | SmartGen | 2400*1100*1600 |
| 68 | ZPW50GF | 3 | 50/55 | 63/69 | 400 | 50 | WP4.1D66E200 | WEICHAI | 60 | 1500 | ZP224D | Zontop | 50 | HGM6110 | SmartGen | 2400*1100*1600 |
| 69 | ZPW60GF | 3 | 60/66 | 75/83 | 400 | 50 | WP4.1D80E200 | WEICHAI | 72 | 1500 | ZP224E | Zontop | 60 | HGM6110 | SmartGen | 2600*1100*1500 |
| 70 | ZPW75GF | 3 | 75/83 | 94/103 | 400 | 50 | WP4.1D100E200 | WEICHAI | 90 | 1500 | ZP274A | Zontop | 80 | HGM6110 | SmartGen | 2600*1100*1500 |
| 71 | ZPW80GF | 3 | 80/88 | 100/110 | 400 | 50 | WP4.1D100E200 | WEICHAI | 90 | 1500 | ZP274A | Zontop | 80 | HGM6110 | SmartGen | 3000*1300*1800 |
| 72 | ZPW100GF | 3 | 100/110 | 125/138 | 400 | 50 | WP6D132E200 | WEICHAI | 120 | 1500 | ZP274B | Zontop | 100 | HGM6110 | SmartGen | 3000*1300*1800 |
| 73 | ZPW120GF | 3 | 120/132 | 150/165 | 400 | 50 | WP6D152E200 | WEICHAI | 138 | 1500 | ZP274C | Zontop | 120 | HGM6110 | SmartGen | 3300*1400*2000 |
| 74 | ZPW150GF | 3 | 150/165 | 188/207 | 400 | 50 | WP10D200E200 | WEICHAI | 182 | 1500 | ZP274E | Zontop | 150 | HGM6110 | SmartGen | 3900*1600*2300 |
| 75 | ZPW200GF | 3 | 200/220 | 250/275 | 400 | 50 | WP10D238E200 | WEICHAI | 216 | 1500 | ZP274H | Zontop | 200 | HGM6110 | SmartGen | 3900*1600*2300 |
| 76 | ZPW250GF | 3 | 250/275 | 313/344 | 400 | 50 | WP10D320E200 | WEICHAI | 291 | 1500 | ZP314B | Zontop | 250 | HGM6110 | SmartGen | 3900*1600*2300 |
| 77 | ZPW300GF | 3 | 300/330 | 375/413 | 400 | 50 | WP13D385E200 | WEICHAI | 350 | 1500 | ZP314D | Zontop | 300 | HGM6110 | SmartGen | 4300*1800*2500 |
| 78 | ZPW350GF | 3 | 350/385 | 438/482 | 400 | 50 | WP13D440E310 | WEICHAI | 392 | 1500 | ZP354A | Zontop | 360 | HGM6110 | SmartGen | 4300*1800*2500 |
| 79 | ZPW400GF | 3 | 400/440 | 500/550 | 400 | 50 | WP13D490E310 | WEICHAI | 450 | 1500 | ZP354B | Zontop | 400 | HGM6110 | SmartGen | 4300*1800*2500 |
| 80 | ZPW450GF | 3 | 450/495 | 563/619 | 400 | 50 | 6M33D572E200 | WEICHAI | 520 | 1500 | ZP354C | Zontop | 450 | HGM6110 | SmartGen | 4900*2100*2700 |
| 81 | ZPW500GF | 3 | 500/550 | 625/688 | 400 | 50 | 6M33D633E200 | WEICHAI | 575 | 1500 | ZP354E | Zontop | 500 | HGM6110 | SmartGen | 4900*2100*2700 |
| 82 | ZPW600GF | 3 | 600/660 | 750/825 | 400 | 50 | 6M33D725E310 | WEICHAI | 675 | 1500 | ZP404A | Zontop | 600 | HGM6110 | SmartGen | 4900*2100*2700 |
| 83 | ZPW650GF | 3 | 650/715 | 813/894 | 400 | 50 | 8M33D800E200 | WEICHAI | 730 | 1500 | ZP404C | Zontop | 728 | HGM6110 | SmartGen | 5500*2300*3000 |
| 84 | ZPW700GF | 3 | 700/770 | 875/963 | 400 | 50 | 12M26D902E200 | WEICHAI | 820 | 1500 | ZP404C | Zontop | 728 | HGM6110 | SmartGen | 6000*2400*3000 |
| 85 | ZPW750GF | 3 | 750/825 | 938/1032 | 400 | 50 | 12M26D902E200 | WEICHAI | 820 | 1500 | ZP404D | Zontop | 800 | HGM6110 | SmartGen | 6000*2400*3000 |
| 86 | ZPW800GF | 3 | 800/880 | 1000/1100 | 400 | 50 | 12M26D968E200 | WEICHAI | 880 | 1500 | ZP404D | Zontop | 800 | HGM6110 | SmartGen | 6000*2400*3000 |
| 87 | ZPW900GF | 3 | 900/990 | 1125/1238 | 400 | 50 | 12M33D1108E200 | WEICHAI | 1007 | 1500 | ZP404E | Zontop | 900 | HGM6110 | SmartGen | 6000*2400*3000 |
| 88 | ZPW1000GF | 3 | 1000/1100 | 1250/1375 | 400 | 50 | 12M33D1210E200 | WEICHAI | 1100 | 1500 | ZP404F | Zontop | 1000 | HGM6110 | SmartGen | 6096*2438*2591 |
| 89 | ZPW1100GF | 3 | 1100/1210 | 1375/1513 | 400 | 50 | 12M33D1320E200 | WEICHAI | 1200 | 1500 | ZP454A | Zontop | 1120 | HGM6110 | SmartGen | 12192*2438*2896 |
| 90 | ZPW1200GF | 3 | 1200/1320 | 1500/1650 | 400 | 50 | 12M33D1500E310 | WEICHAI | 1350 | 1500 | ZP454B | Zontop | 1240 | HGM6110 | SmartGen | 12192*2438*2896 |
| 91 | ZPW1250GF | 3 | 1250/1375 | 1563/1719 | 400 | 50 | 16M33D1530E310 | WEICHAI | 1390 | 1500 | ZP454C | Zontop | 1320 | HGM6110 | SmartGen | 12192*2438*2896 |
| 92 | ZPW1400GF | 3 | 1400/1540 | 1750/1925 | 400 | 50 | 16M33D1680E310 | WEICHAI | 1530 | 1500 | ZP454D | Zontop | 1440 | HGM6110 | SmartGen | 12192*2438*2896 |
| 93 | ZPW1500GF | 3 | 1500/1650 | 1875/2063 | 400 | 50 | 16M33D1800E310 | WEICHAI | 1680 | 1500 | ZP454E | Zontop | 1520 | HGM6110 | SmartGen | 12192*2438*2896 |
| 94 | ZPW1600GF | 3 | 1600/1760 | 2000/2200 | 400 | 50 | 16M33D1980E310 | WEICHAI | 1800 | 1500 | ZP454F | Zontop | 1640 | HGM6110 | SmartGen | 12192*2438*2896 |
